Custom Stainless Steel Wire Products Built Precisely

Stainless steel wire is widely used where corrosion resistance, strength, heat tolerance, and long service life are important. In knitted mesh form, common uses include air, liquid, and gas filtration; mist elimination; separation; insulation blanket reinforcement; catalytic converter components; vibration damping; sealing; and EMI/RFI shielding. It is also used in automotive, aerospace, chemical processing, food and beverage, and process equipment applications.

Type 304 stainless steel wire is a versatile, widely used grade with strong corrosion resistance and good mechanical performance in many general industrial environments. Type 316 includes molybdenum, which improves resistance to chlorides and more aggressive chemical exposure. Selecting between them should consider process media, temperature, moisture, cleaning chemicals, corrosion risk, and the required service life of the finished component.

Yes. Gemini Wiremesh manufactures custom stainless steel knitted mesh in rolls, cut lengths, flattened or crimped forms, and shaped components. Specifications can include wire diameter, mesh grade, width, length, density, thickness, porosity, and final configuration. Compressed mesh can also be formed into rings, gaskets, seals, spacers, and other shapes suited to the mating component or process equipment.

The right mesh depends on the fluid or gas being filtered, required particle retention, flow rate, pressure drop, operating temperature, and exposure to chemicals or vibration. Knitted stainless steel mesh filters offer flexibility and high surface area, while density, wire diameter, thickness, and porosity can be adjusted to achieve the intended balance of contaminant capture and flow performance.

Stainless steel knitted wire mesh is well suited to elevated-temperature applications because it retains strength and resists oxidation and physical damage better than many non-metallic filter media. Actual temperature capability depends on the stainless grade, process atmosphere, thermal cycling, and component design. Providing those operating details during specification helps ensure the selected wire and mesh construction are appropriate.

A useful custom request includes the application, operating medium, temperature, pressure, corrosion conditions, desired material grade, target dimensions, mesh form, and estimated quantity. For filtration or separation, include flow rate, allowable pressure drop, and retention objective where available. A drawing, sample, or photos of the existing component can also help define fit, tolerances, and the required configuration.

Many stainless steel knitted wire mesh filters can be cleaned and reused when the process, contaminant type, and component condition allow it. Their metal construction withstands shock, vibration, heat, and challenging fumes better than many paper or cloth alternatives. The cleaning method should be compatible with the wire grade and application, and a filter should be replaced if damage or permanent blockage affects performance.

A custom demister pad is sized and configured for the vessel, gas velocity, droplet load, available pressure drop, and operating environment. Properly specified knitted mesh captures entrained liquid droplets while allowing gas to pass through, helping protect downstream equipment and product quality. Custom shapes and materials also improve installation fit and make removal for cleaning or replacement more straightforward.
